8-23
8
3. If the level is low, add sufficient oil of the
recommended type to raise it to the
specified level. NOTICE: Be sure no for-
eign material enters the differential
gear case.
[ECB00412]
4. Check the gasket for damage, and re-
place it if necessary.
5. Install the differential gear oil filler bolt
and its gasket, and then tighten the bolt
to the specified torque.
Changing the differential gear oil
1. Park the vehicle on a level surface.
2. Remove the front bottom panel by re-
moving the bolts.
3. Place an oil pan under the differential
gear case to collect the used oil.
1. Differential gear oil filler bolt
2. Gasket
3. Differential gear oil
4. Correct oil level
Tightening torque:
Differential gear oil filler bolt:
23 Nm (2.3 m·kgf, 17 ft·lbf)
1. Front bottom panel
2. Bolt
