Yamaha WOLVERINE 2015 - Instrument and Control Functions

4-1
4
EBU31213
INSTRUMENT AND CONTROL
FUNCTIONS
EBU31220
Main switch
Functions of the respective switch positions
are as follows:
EBU31230
“” (on):
All electrical circuits are supplied with power.
The key cannot be removed.
TIP
The helmet indicator light comes on and stays
on while the key is turned to “ ” (on).
EBU31240
“ ” (off):
All electrical circuits are switched off. The key
can be removed.
EBU31250
“ ” (start):
The electric starter is engaged by turning and
holding the key in this position. Release the
key when the engine starts.
1. Main switch
2. “ ” (off)
3. “ ” (on)
4. “ ” (start)
1
2
3
4
