8-31
8
23. Stop the engine and allow it to cool. If the
coolant level has dropped after the en-
gine has cooled, add sufficient coolant
until it reaches the top of the radiator, and
then install the radiator cap.
24. Check the coolant level in the reservoir. If
necessary, remove the coolant reservoir
cap, add coolant to the maximum level
mark, and then install the cap.
25. Start the engine, and then check for cool-
ant leakage.
If any leakage is found, have a Yamaha dealer
check the cooling system.
26. Install the center bottom panel by install-
ing the bolts, and then tightening them to
the specified torque.
27. Install the panels and the hood.
EBU32400
Axle boots
Check the axle boots for holes or tears.
If any damage is found, have them replaced
by a Yamaha dealer.
Tightening torques:
Center bottom panel bolt
9 Nm (0.9 m·kgf, 6.5 ft·lbf)
1. Front axle boot
