4-28
4
EWB00411
These shock absorber assemblies contain
highly pressurized nitrogen gas. Read and
understand the following information be-
fore handling the shock absorber assem-
blies.
Do not tamper with or attempt to open
the cylinder assemblies.
Do not subject the shock absorber as-
semblies to an open flame or other high
heat source. This may cause the unit to
explode due to excessive gas pressure.
Do not deform or damage the cylinders
in any way. Cylinder damage will result in
poor damping performance.
Do not dispose of a damaged or worn
out shock absorber assembly yourself.
Take the shock absorber assembly to a
Yamaha dealer for any service.
EBU33620
Adjusting the rear shock absorber as-
semblies
These shock absorber assemblies are
equipped with a spring preload adjusting nut,
a rebound damping force adjusting screw, a
compression damping force adjusting bolt
(for fast compression damping), and a com-
pression damping force adjusting screw (for
slow compression damping).
EWB02492
Suspension components become hot
during operation. Never touch the com-
pression damping force adjusting bolt
Compression damping setting (for slow com-
pression damping):
Minimum (soft):
18 click(s) in direction (b)*
Standard:
12 click(s) in direction (b)*
Maximum (hard):
1 click(s) in direction (b)*
* With the adjusting screw fully turned in di-
rection (a)
UBN57AE0.book Page 28 Tuesday, November 24, 2015 1:42 PM
