8-21
8
Changing the final gear oil
1. Park the vehicle on a level surface.
2. Remove the rear bottom panel by remov-
ing the bolts.
3. Place an oil pan under the final gear case
to collect the used oil.
4. Remove the final gear oil filler bolt, the fi-
nal gear oil drain bolt and their gasket to
drain the oil.
5. Install the drain bolt and its new gasket,
and then tighten the bolt to the specified
torque.
Tightening torque:
Final gear oil filler bolt:
23 Nm (2.3 m·kgf, 17 ft·lbf)
1. Rear bottom panel
2. Bolt
1. Final gear oil drain bolt
2. Gasket
Tightening torque:
Final gear oil drain bolt:
22 Nm (2.2 m·kgf, 16 ft·lbf)
