Yamaha XT660Z Tenere 2008 User Manual

4-14
REAR WHEEL
Removing the rear wheel
EAS22020
REAR WHEEL
Order Job/Parts to remove Q’ty Remarks
NOTE:
Place the vehicle on a suitable stand so that
the front wheel is elevated.
1 Rear wheel axle nut 1
2 Drive chain adjusting locknut (left and right) 2 Loosen.
3 Drive chain adjusting bolt (left and right) 2 Loosen.
4 Drive chain 1 Remove from the rear sprocket.
5 Rear wheel axle 1
6 Rear wheel 1
For installation, reverse the removal
procedure.

Yamaha XT660Z Tenere 2008 Specifications

General

Displacement	660cc
Compression Ratio	10.0:1
Maximum Power	35.0 kW (48 PS) @ 6, 000 rpm
Fuel System	Fuel injection
Ignition System	TCI
Starter System	Electric
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Front Tire	90/90-21
Rear Tire	130/80-17
Seat Height	895 mm
Dry Weight	183 kg
Front Suspension Travel	210 mm
Rear Suspension Travel	200 mm
Height	1, 477 mm
Wheelbase	1, 505 mm
Ground Clearance	260 mm
Engine Type	Single cylinder, 4-stroke, SOHC, 4 valves
Bore x Stroke	100 mm x 84 mm
Rear Suspension	Swingarm
Rear Brake	Single disc, Ø 245 mm
Fuel Capacity	22 litres
Wet Weight	206 kg
Front Brake Disc	298 mm
Rear Brake Disc	245 mm
Width	865 mm
Length	2, 246 mm
