Yamaha XT660Z Tenere 2008 User Manual

2-13
ELECTRICAL SPECIFICATIONS
ELECTRICAL SPECIFICATIONS
Voltage
System voltage 12 V
Engine control unit
Model/manufacturer TBDF84/DENSO
Ignition system
Ignition system type Transistorized coil ignition (digital)
Ignition timing 5.0° (B.T.D.C.) at 1450 r/min
Advancer type Electrical
Pickup coil resistance/color 192-288
Ω at 20 °C (68 °F)/
blue/yellow-green/white
Transistorized coil ignition unit TBDF55/DENSO
model/manufacture
Ignition coil
Model/manufacturer JO300/DENSO
Minimum ignition spark gap 6.0 mm (0.24 in)
Primary coil resistance 3.40-4.60
Ω at 20 °C (68 °F)
Secondary coil resistance 10.4-15.6 k
Ω at 20 °C (68 °F)
Spark plug cap
Material Resin
Resistance 10.0 k
Ω at 20 °C (68 °F)
Charging system
System type A.C. magneto
Model/manufacturer LMX51/DENSO
Nominal output 14.0 V/20.8 A at 5000 r/min
Stator coil resistance/color 0.224-0.336
Ω at 20 °C (68 °F)/white-white
Rectifier/regulator
Regulator type Semi conductor-short circuit
Model/manufacturer SH678-11/SHINDENGEN
No-load regulated voltage 14.1-14.9 V
Rectifier capacity 35.0 A
Withstand voltage 200.0 V
Battery
Model/manufacter GT9B-4/GS YUASA
Voltage, capacity 12 V, 8.0 Ah
Specific gravity 1.320
Ten hour rate amperage 0.8 A
Headlight
Headlight type Bulb type
Bulb type Halogen bulb

Yamaha XT660Z Tenere 2008 Specifications

General

Displacement	660cc
Compression Ratio	10.0:1
Maximum Power	35.0 kW (48 PS) @ 6, 000 rpm
Fuel System	Fuel injection
Ignition System	TCI
Starter System	Electric
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Front Tire	90/90-21
Rear Tire	130/80-17
Seat Height	895 mm
Dry Weight	183 kg
Front Suspension Travel	210 mm
Rear Suspension Travel	200 mm
Height	1, 477 mm
Wheelbase	1, 505 mm
Ground Clearance	260 mm
Engine Type	Single cylinder, 4-stroke, SOHC, 4 valves
Bore x Stroke	100 mm x 84 mm
Rear Suspension	Swingarm
Rear Brake	Single disc, Ø 245 mm
Fuel Capacity	22 litres
Wet Weight	206 kg
Front Brake Disc	298 mm
Rear Brake Disc	245 mm
Width	865 mm
Length	2, 246 mm
