CHAIN DRIVE
4-68
EAM20104
CHAIN DRIVE
Removing the drive chain
Order Job/Parts to remove Q’ty Remarks
Drive sprocket Refer to “ENGINE REMOVAL” on page 5-6.
1 Drive chain 1
2 Drive sprocket cover 1
3 Bracket 1
4 Drive sprocket nut 1
5 Lock washer 1
6 Drive sprocket 1
1
2
3
4
5
6
7 N・m (0.7 kgf・m, 5.2 lb・ft)
90 N・m (9.0 kgf・m, 66 lb・ft)
