INSTRUMENT AND CONTROL FUNCTIONS
1-23
EAM30192
FUEL TANK CAP
Fuel tank cap “1” is located under the fuel tank
cap cover “2”.
Remove the fuel tank cap cover to open the fuel
tank cap.
• To remove the fuel tank cap cover, insert fin-
gers under part “a”, and then use both hands to
lift it up towards the rear of the vehicle.
• Install the fuel tank cap cover after placing the
bands “3” all the way in under the seat.
1
2
3
a
a
2
