TROUBLESHOOTING
9-11
EAM30516
TROUBLESHOOTING OF CHARGING SYSTEM
Front wheel vibration
Incorrect wheel balance Adjust the wheel balance.
Loose spoke
Tighten the spoke and adjust the
runout.
Damaged or worn wheel bearing Replace the wheel bearing.
Worn, deformed, or incorrect tire Replace the tire.
Loose wheel axle or wheel axle
nut
Tighten the wheel axle or wheel
axle nut to the specified torque.
Loose wheel axle pinch bolt
Tighten the wheel axle pinch bolt
to the specified torque.
Incorrect front fork oil level
Adjust to the specified front fork oil
level.
Rear wheel vibration
Incorrect wheel balance Adjust the wheel balance.
Loose spoke
Tighten the spoke and adjust the
runout.
Damaged or worn wheel bearing Replace the wheel bearing.
Worn, deformed, or incorrect tire Replace the tire.
Loose wheel axle nut
Tighten the wheel axle nut to the
specified torque.
Loose swingarm pivot shaft
Tighten the swingarm pivot shaft
to the specified torque.
Bent or damaged swingarm Replace the swingarm bearing.
Damaged or worn swingarm bear-
ing or bushing
Replace the swingarm bearing or
bushing.
Symptom Possible cause Actions
Battery is not charged
Refer to “TROUBLESHOOTING” under “CHARGING SYSTEM” on
page 8-11.
Symptom Possible cause Actions
