CHASSIS
10-5
• Spring preload adjusting positions
For the spring preload adjustment, refer to “AD-
JUSTING THE REAR SHOCK ABSORBER AS-
SEMBLY” on page 3-30.
Spring preload adjusting positions
Minimum
Position in which the spring is
turned in 1.5 mm (0.06 in) from
its free length.
Standard
Position in which the spring is
turned in 7.0 mm (0.28 in) from
its free length.
Maximum
Position in which the spring is
turned in 18.0 mm (0.71 in) from
its free length.
1
a
