CHASSIS SPECIFICATIONS
2-5
EAM20129
CHASSIS SPECIFICATIONS
Chassis
Frame type Semi double cradle
Caster angle 26.9
Trail 120 mm (4.7 in)
Front wheel
Wheel type Spoke wheel
Rim size 21x1.6
Radial wheel runout limit 2.0 mm (0.08 in)
Lateral wheel runout limit 2.0 mm (0.08 in)
Wheel axle bending limit 0.50 mm (0.02 in)
Rear wheel
Wheel type Spoke wheel
Rim size 19x2.15
Radial wheel runout limit 2.0 mm (0.08 in)
Lateral wheel runout limit 2.0 mm (0.08 in)
Wheel axle bending limit 0.50 mm (0.02 in)
Front tire
Type With tube
Size 80/100-21 51M
Manufacturer/model DUNLOP/MX33
Rear tire
Type With tube
Size 120/80-19 63M
Manufacturer/model DUNLOP/MX33
Tire air pressure (measured on cold tires)
Front 100 kPa (1.00 kgf/cm², 15 psi)
Rear 100 kPa (1.00 kgf/cm², 15 psi)
Front brake
Type Hydraulic single disc brake
Brake disc thickness limit 2.5 mm (0.10 in)
Brake disc runout limit (as measured on
wheel)
0.15 mm (0.0059 in)
Brake pad lining thickness limit 1.0 mm (0.04 in)
Master cylinder inside diameter 9.52 mm (0.37 in)
Caliper cylinder inside diameter (Left) 25.40 mm, 25.40 mm (1.00 in, 1.00 in)
Specified brake fluid DOT 4
Rear brake
Type Hydraulic single disc brake
Brake pedal position 5.0 mm (0.20 in)
Brake disc thickness limit 3.5 mm (0.14 in)
Brake disc runout limit (as measured on
wheel)
0.15 mm (0.0059 in)
Brake pad lining thickness limit 1.0 mm (0.04 in)
Master cylinder inside diameter 11.0 mm (0.43 in)
Caliper cylinder inside diameter 25.40 mm (1.00 in)
Specified brake fluid DOT 4
