Operation Using SFC Yamatake Corporation
6-16 ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter
6-4 : Check during operation
6-4-1 :Starting communication: ID/DE READ key
CAUTION
Before starting communication between the SFC in a system with analog output and
the transmitter, be sure to change the control loop to “manual control”. This is to pre-
vent fluctuation in analog output of the transmitter, which is caused by starting the
SFC and communicating with the transmitter, from directly affecting the control loop.
Use the following procedure to start the SFC. The key operations of the SFC and dis-
play of the display window slightly vary depending on whether the system has digital
output or analog output.
Step Procedure SFC screen
1 Connect the communication cable of SFC to
the transmitter.
2 Make sure the wiring between the transmitter
signal line and SFC is correct.
3 Turn the SFC on.
Result:
- The SFC executes self-diagnostics and the
screen to the right appears.
Turn on the power switch of the SFC. After
checking that the process is in manual control
mode, press the key.
4
Press the key.
5 Read the tag number (displayed in the data
display window). Check whether the SFC is
connected to the correct transmitter.
• If not, connect the communication cable to
the correct transmitter.Repeat from step 2.
ENTER
( Yes )
NON-VOL
SELF CHECK...
LOOP IN MANUAL?
PRESS ID
A
ID
DE READ
WORKING...
DSTJ TAG NO.
LIN DP FIT-1234
DSTJ TAG NO.
LIN DP FIT-1234
To Next Page
