Operation Using SFC Yamatake Corporation
6-22 ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter
Printing example
An example of an action printout corresponding to actual key operation will be
explained.
7
Press the (ACT PR) key.
8
Press the key.
Result:
The action printout operation ends by
printing:
* ACTION PRINT * END
Then, the screen returns to that of step 2.
Step Procedure SFC screen
Z
0
ACT PR
DSTJ FIT-1234
ACTION PRINT?
CLR
( No )
Z
0
ACT PR
SHIFT
ENTER
( Yes )
NON-VOL
keys
0
SHIFT
CLR
( No )
keys
C
DAMP
keys
* ACTIONPRINT * START
TAG. No. FIT-1234
'01. 07. 10 16:11
DAMP FIT-1234
0.0 s
SPAN FIT-1234
300.0 mm
LRV FIT-1234
0.000 mm
* ACTION PRINT * END
Key operation
Printing example of
corresponding action printout
