Operation Using SFC Yamatake Corporation
6-34 ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter
7
Press the key.
Set the high limit of engineering quantity
(50.0).

8
Press the key.
Press the key.
Changes the high and low limits of engi-
neering quantity to the set values.

9
Press the key
10
Press the and keys in that
order.
Saves the data in the transmitter.

Step Description SFC screen
ENTER
( Yes )
NON-VOL
EUHI (at 100%)
ENTERED IN SFC
EUHI (at 100%)
50.0
H
NEXT
ENTER
( Yes )
NON-VOL
DISPLAY
DOWNLOAD DAT.?
DISPLAY
WORKING...
DISPLAY
DATA LOADED!
DSTJ CONFIG
DISPLAY?
CLR
( No )
DSTJ FIT-1234
READY...
SHIFT
ENTER
( Yes )
NON-VOL
SHIFT-
DSTJ FIT-1234
WORKING...
DSTJ FIT-1234
DATA NONVOLATILE
DSTJ FIT-1234
READY...
