YAMAZAKI MAZAK INTEGREX e Series User Manual

4 MACHINING PROGRAM
4-76
G90G43G0X0.0Y0Z0.0 H1P1
M250
G274R1.0
G274X0Z-80.0P0Q15.0F0.2
G0X100.0Z0.0
G80
G40
M205
M952
M09
G91G28X0
G28Z0
G28Y0
G28B0
M30
G109L2
M902
M302
G00G18G90G95G54G96
G40G49G80G67G69
G0X0
G0Z-100.
M950
T101000
G91G28X0
G28Z0
G92S2000R1
G96M303S150R1
G10.9X1
M08
M951
G90G43G0X-180.Z-150.0 H1
M250
G91X-150.Z-130.
G1Z-100.F0.25
X-180.
G90G0X-200.Z-150.0
G40
M305
M952
M09
G91G28X0
G28Z0
M30
(Upper turret: HD1- Turning, Lower turret: HD2- Turning (2/2))
jiku
Preparation motion for machining
 G109L2: Lower turret selection
 M902: HD2 spindle selection
 M302: C-axis disconnect / turning mode
 G95: Feed per revolution
 G96: Constant surface speed control ON
 T101000: Tool change (TNo.101 Lower)
 G92S2000: Spindle speed range setting
 S96S150: Surface speed 150 m/min
 R1: Set the HD2
 M303: Turning spindle2 forward rotation
 G10.9X1: Diameter data input mode
 M08: Flood coolant ON
Machining motion
End motion for machining
 M305: Turning spindle2 Rotation stop
 M09: All coolants OFF
 Each axis positioning to zero return
 M30: Reset and rewind
Machining
Machining
End motion for machining
 M205: Turning spindle1 Rotation stop
 M09: All coolants OFF
 Each axis positioning to zero return
 M30: Reset and rewind
