4 MACHINING PROGRAM
4-16
B. Program composition
C. Relevant parameter setting
The main parameter of processing is described.
The table shows the standard parameter and setting set in this manual.
Parameter setting
Parameter
bit
Standard
Setting
Description
F114
3
1
1
Moving axes by using G49 (tool length offset cancel) in G43 (tool
length offset) mode Invalid
SU104
-
Pecking return distance in grooving (G274/G275, G74/G75)
G00G90G43XxYyZzHhP1
M250
M107
G274Rr
G274X0ZzQqFf
G0XxZz
G80
Machining motion of program composition – Turn–drilling operation
--- Tool Length offset (for Turning)
--- Spindle speed attainment check
--- B-axis clamping
--- G274 input
--- G274 input (X address is zero)
--- Escape
--- Fixed cycle (G274) OFF
Command in
machining motion
Command in
preparation motion
for machining
Upper turret
HD1
Turning
Tool length offset (P1)
Compound fixed cycle
Program composition element
