4-4-2 Hole machining program
This section explains how to make hole-machining program.
1. Hole machining
This section explains hole machining program using fixed cycles.
A. Sample program
G109L1
M901
M200
M212
G0G90G94G55G97
G40G49G80G67G69
G91G28X0
G28Z0
G28Y0
T001T00M06
G91G28X0
G28Y0
G28Z0
M108
G90G53B45.0
G97S2500M03
G10.9X0
M08
M212M108
G68.2P1X0Y0Z0I0J45K0
G53.1
M210M107
G90G43G00X42.271Y7.62Z3.H1
G82Z-1.R3.F115.
Y0.
Y-7.62
G80
Z50.0
G69
M05
M09
G91G28X0
G28Z0
G28Y0
M108
G90G53B0
M30
Preparation motion for machining
 G109L1: Upper turret selection
 M901: HD1 spindle selection
 M200: C-axis connect/Milling mode select
 M212: C-axis unclamping
 G94: Feed per minute
 G97: Constant surface speed control OFF
 T001M06: Tool change (TNo.01)
 B-axis positioning
 G97S2500: Rotation speed 2500 min
-1
 M03: Mill spindle forward rotation
 G10.9X0: Radius data input mode
 M08: Flood coolant
Machining motion
 M212M108: Rotation axes unclamping
 G68.2: Inclined-plane machining
 P1: Using roll, pitch, and yaw angles
 G53.1: Tool-axis direction control
 M210M107: Rotation axes clamping
 G43H**(P0): Tool length offset
 G82: Drilling cycle
 (Drilling motion)
 G80: Fixed cycle OFF
 G69: Inclined-plane machining OFF
End motion for machining
 M05: Stop of milling spindle rotation
 M09: All coolants OFF
 Each axis positioning to zero return
 M30: Reset and rewind
(Drill fixed cycle )
