5 SUPPLEMENT
5-18
7. G-code (Group08)
A. Tool length offset
1. Command
Programming format
G43 Zz Hh Pp
(TOOL OFFSET) (Note 1)
G43 Zz
(MAZATROL TOOL DATA) (Note 1)
Cancellation
G49 (Note 2)
Function
Commands G43 allow the ending point of execution of move commands to be shifted
through the previously set offset amount for each axis. Any deviations between
programmed tool lengths/diameters and actual lengths/diameters can be set as offset data
using these commands to make the program more flexible.
Code value
Description
Unit
Setting range
Omit
G43
Tool length offset (+)
z
Position of Z-axis
mm
in
±99999.9999 (mm)
±9999.99999 (in)
Possible
h
Tool offset number
1 to Maximum offset No.
p
Tool type of upper turret
(P0:Milling, P1: Turning)
0, 1
Possible (0)
Note 1: It depends on the setting of F93 bit3 and F94 bit7 whether TOOL OFFSET or
MAZATROL TOOL DATA is selected.
Data items used
Parameter
Programming format
F94 bit7
F93 bit3
Tool offset
Tool offset No.
0
0
G43 H
Tool Data (MAZATROL)
LENGTH
1
1
T + G43
LENGTH + OFFSET No.
LENGTH + LENG CO.
T + G43 H
OFFSET No.
LENG CO.
1
0
G43 H
Tool offset + Tool
Tool offset No. + LENGTH
0
1
T+ G43 H
Note 2: Selection of canceling operation by G49 in the mode of G43.
Parameter
Description
F114 bit3
Moving axes by using G49 in G43 mode
0: Cancellation with axis movement for clearing the length offset amount
1: Cancellation without axis movement
2. Notes
 Set G43 H0 if tool length offsetting is to be done using a G43 H-command and only the
offset amount specified by H is to be cancelled.
