MACHINE INFORMATION 2
2-25
B. On milling (During geometry compensation)
[mm/min (in/min) or deg/min]
Machine specification
X
Y
Z
B
C
W
e-420H
1500U
50000
(1962)
50000
(1962)
50000
(1962)
50000
50000
50000
(1962)
3000U
e-500H
1500U
10800
7200
3000U
4000U
e-670H
3000U
4000U
6000U
e-800H
4000U
20000
(785)
20000
(785)
20000
(785)
4500
20000
(785)
6000U
8000U
5. INTEGREX e-H-S
A. On turning/milling
[mm/min (in/min) or deg/min]
Machine specification
X
Y
Z
B
C1
W
C2
e-420HS
1500U
8000
(314)
8000
(314)
8000
(314)
7200
36000
8000
36000
3000U
e-500HS
1500U
2100
1800
1800
3000U
e-670HS
3000U
4000U
B. On milling (During geometry compensation)
[mm/min (in/min) or deg/min]
Machine specification
X
Y
Z
B
C1
W
C2
e-420HS
1500U
50000
(1962)
50000
(1962)
50000
(1962)
50000
50000
50000
(1962)
50000
3000U
e-500HS
1500U
10800
7200
7200
3000U
e-670HS
3000U
4000U
6. INTEGREX e-H-ST
A. On turning/milling
[mm/min (in/min) or deg/min]
Machine specification
X1
Y
Z1
B
C1
W
C2
e-420HST
2000U
8000
(314)
8000
(314)
8000
(314)
7200
36000
8000
(314)
36000
Machine specification
X2
Z2
e-420HST
2000U
8000
(314)
8000
(314)
