6. FUEL INJECTION EQUIPMENT
122
6. FUEL INJECTION EQUIPMENT
6.1 Fuel Injection Pump/Governor
Refer to the JH3E manual of separate volume for the disassembly and assembly, adjustment procedure
of a fuel injection pump.
6.1.1 Fuel system diagram
Fuel injection pump
Feed pump
Fuel nozzle
Fuel injection pipe
Fuel return pipe
Fuel filter
From fuel tank
Water separator
To fuel tank
