14. TIGHTENING TORQUE FOR BOLTS AND NUTS
197
14. TIGHTENING TORQUE FOR BOLTS AND NUTS
14.1 Main Bolt and Nut
14.2 Standard Bolts and Nuts (without lube oil)
No Name
Thread diameter
x pitch (mm)
Lubricating oil application
(thread portion, and seat
surface)
Torq u e
N•m(kgf-m)
1 Head bolt M10 x 1.25 Coat with lube oil 85.2-91.2 (8.69-9.30 )
2 Rod bolt M9 x 1.0 Coat with lube oil 44.1-49.1 (4.50-5.01)
3 Flywheel retainer bolt M10 x 1.25 Coat with lube oil 83.3-88.3 (8.49-9.00)
4 Metal cap retainer bolt M12 x 1.5 Coat with lube oil 96-100 (9.79-10.2)
5
Crankshaft pulley bolt
(FC300 pulley)
M14 x 1.5 Coat with lube oil 83.2-93.2 (8.48-9.50)
6 Fuel pump gear nut M14 x 1.5 Coat with lube oil 78-88 (8-9)
7 Nozzle fastening bolt M8 x 1.25 No lube oil 24.4-28.4 (2.49-2.90)
8
Fuel injection pipe
joint nut
M12 x 1.5 No lube oil 29.4-34.4 (3.00-3.51)
9
Starter relay terminal
nut
M6 x 1 No lube oil 3.0-4.2 (0.31-0.43)
N•m (kgf-m)
Name Screw dia. x pitch (mm) Tightening torque Remarks
Hexagon bolt t (7T)
and nut
M6 x 1 9.8-11.8 (1.0-1.2) Use 80% of the value at
left when the tightening
part is aluminum.
Use 60% of the value at
left for 4T bolts and lock
nuts.
M8 x 1.25 22.5-28.5 (2.3-2.9)
M10 x 1.5 44-54 (4.5-5.5)
M12 x 1.75 78.2-98.2 (8.0-10.0)
PT plug 1/8 9.8 (1.0)
1/4 19.6 (2.0)
3/8 29.4 (3.0)
1/2 58.8 (6.0)
Pipe joint bolt M8 12.7-16.7 (1.3-1.7)
M10 19.5-25.5 (2.0-2.6)
M12 24.4-34.4 (2.5-3.5)
M14 39.1-49.1 (4.0-5.0)
M16 48.9-58.9 (5.0-6.0)
