4. Disassembly and Reassembly
64
Name of tool Illustration Remarks
Press tool 1 for filler
neck
-
Press tool 2 for filler
neck copper tube
-
Stem seal insertion
(for inserting stem
seal)
-
(Tool 1)
25
27.5 35.5
40
89
2
1
105
30 30
170
24.2
28
30
(Tool 2)
Chamfer
mm
d1
16.2 22 13.5 18.8 65 4
d2 d3 L1 L2 L3
L
2
L
1
d
1
d
2
L 2
L 1
L 3
d 1
d 2
d 3
