Engine Model 4JH4-TE
Marine Gear Model ZF30M KM4A2 KMH4A ZF25A SD50-4T Bobtail
Engine
dimension
Overall length 923 mm
(36.3 in.)
903 mm
(35.6 in.)
933 mm
(36.7
in.)
1017 mm
(40.0 in.)
782 mm
(30.8 in.)
782 mm
(30.8
in.)
Overall width 616 mm
(24.3 in.)
Overall height 659 mm
(25.9 in.)
Flywheel major dimension D339 x 66 mm
(13.3 x 2.6 in.)
Engine dry mass
(including marine gear)
235 kg
(518 lb)
237 kg
(523 lb)
238 kg
(525 lb)
237 kg
engine:
173 kg
(523 lb)
(engine:
381 lb)
249 kg
(engine: 207
kg) (549 lb)
(engine: 456 lb)
207 kg
(456 lb)
*
Rating Condition: Temperature of fuel; 40˚C at fuel pump inlet; ISO 8665
**
The “total” oil quantity includes oil in oil pan, channels, coolers and filter.
***
The effective amount of oil shows the difference in maximum scale of the dipstick and minimum scale.
Note: Density of fuel: 0.842g/cm
3
at 15˚C. Fuel temperature at the inlet of the fuel injection
pump.
1 hp metric = 0.7355 kW
SPECIFICATIONS
JH4 Series Operation Manual 97
