LOCATION OF
NAMEPLATES
The nameplates of Yanmar JH4 series
engines are shown in Figure 9 and
Figure 10. Check the engine's model,
output, rpm and serial number on the
nameplate. Please replace if damaged or
lost.
The engine nameplate is attached to the
engine rocker arm cover.
Continuous power kW
Speed of prop shaft
Gear Model
min
-1
Fuel stop power kW
ENG.No.
min
-1
min
-1
MADE IN JAPAN
Model
Figure 9
//
Gear Model
ENG.No.
//
Model
min
-1
min
-1
min
-1
Continuous power kW
Speed of prop,shaf t
Fuel stop power kW
0004574
Figure 10
The marine gear nameplate (Figure 11) is
attached to the marine gear. Check the
marine gear's model, gear ratio, oil used, oil
quantity and serial number
MODE L KM
GEAR RATIO
OIL SAE
20
/30 HD
OIL QT Y. LTR.
NO.
0004529
Figure 11
The sail drive nameplate (Figure 12) is
attached to the sail drive. Check the sail
drive model and serial number.
MADE IN JAPAN
MODEL
PASSED
MARK
MFG.NO.
0004575
Figure 12
