Engine Model 4JH4-HTE
Marine Gear Model ZF30M KM4A2 KMH4A ZF25A Bobtail
Engine
dimension
Overall length 923 mm
(36.3 in.)
903 mm
(35.6 in.)
933 mm
(36.7 in.)
1017 mm
(40.0 in.)
782 mm
(30.8 in.)
Overall width 616 mm
(24.3 in.)
Overall height 659 mm
(25.9 in.)
Flywheel major dimension D339 x 66 mm
(13.3 x 2.6 in.)
Engine dry mass
(including marine gear)
245 kg
(540 lb)
247 kg
(545 lb)
248 kg
(547 lb)
247 kg
(545 lb)
217 kg
(478 lb)
*
Rating Condition: Temperature of fuel; 40˚C at fuel pump inlet; ISO 8665
**
The “total” oil quantity includes oil in oil pan, channels, coolers and filter.
***
The effective amount of oil shows the difference in maximum scale of the dipstick and minimum scale.
Note: Density of fuel: 0.842g/cm
3
at 15˚C. Fuel temperature at the inlet of the fuel injection
pump.
1 hp metric = 0.7355 kW
SPECIFICATIONS
JH4 Series Operation Manual 99
