C-Type
0004503
(1)
(5) (6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(2)
(3)
(4)
Figure 14
1 – Coolant High Temperature Indicator
2 – Coolant Temperature Gauge
3 – Engine Oil Low Pressure Indicator
4 – Engine Oil Pressure Gauge
5 – Tachometer
6 – Hourmeter
7 – Moisture Cap for Key Switch
8 – Key Switch
9 – Stop Button
10 – Battery Low Charge Indicator
11 – Water in Sail Drive Seal Indicator
12 – Water in Fuel Filter Indicator (if
equipped)
13 – Insufficient Seawater Flow Indicator
PRODUCT OVERVIEW
22 JH4 Series Operation Manual
