Specification 3JH4E
Marine Gear Model KM35P KM35A SD40/SD50 Bobtail
Lubricating oil
capacity
(engine)
Rake angle at rake angle 8˚ at rake angle 0˚ -
Total
***
5.0 ± 0.3 L
(5.3 ± 0.3 qt)
5.5 ± 0.3 L
(5.8 ± 0.3 qt)
Oil pan only 4.5 ± 0.3 L (4.8 ±
0.3 qt)
5.0 ± 0.3 L (5.3 ± 0.3 qt)
Effective
****
1.1 L (1.2 qt) 1.2 L (1.3 qt)
Starting
system
Type Electric
Starting motor DC 12 V - 1.4 kW
AC generator 12 V - 80 A (12 V - 60 A optional)
Engine
dimension
Overall length 777 mm
(30.6 in.)
776 mm (30.6 in.) 700 mm
(27.6 in.)
Overall width 539 mm (21.2 in.)
Overall height 623 mm (24.5 in.)
Flywheel major dimension D300 x 66 mm (11.8 x 2.6 in.)
Engine dry mass (include marine
gear)
185 kg
(408 lb)
186 kg
(410 lb)
213 kg engine:
173 kg (470 lb)
(engine: 381 lb)
173 kg
(467 lb)
*
Rating Condition: Temperature of fuel; 25˚C at fuel pump inlet; ISO 3046-1
**
Rating Condition: Temperature of fuel; 40˚C at fuel pump inlet; ISO 8665
***
The “total” oil quantity includes oil in oil pan, channels, coolers and filter.
****
The effective amount of oil shows the difference in maximum scale of the dipstick and minimum scale.
Note: Density of fuel: 0.842g/cm
3
at 15˚C. Fuel temperature at the inlet of the fuel injection
pump.
1 hp metric = 0.7355 kW
SPECIFICATIONS
88 JH4 Series Operation Manual
