Yanmar
®
600 Control Panel Operation and Troubleshooting
2 463-3000-09 Initial - 16-May-2008
Note
Most problems with electronically controlled engines can be pinpointed via ECU diagnostic
messages. Use the display or ECU diagnostic tool to view fault codes.
Engine state information and diagnostic codes
displayed by the CANplus display are provided via the CANbus.
Throttle Control
The standard Ramp Throttle uses a momentary rocker switch to adjust the integral throttle control. All throttle
commands are sent directly to the engine using CANbus throttle control.
Note
Throttle control requires CANbus throttling to be enabled in the ECU.
CANbus throttling is also known as Torque Speed Control or TSC1.
Rotary potentiometers are available for ECUs that do not support CANbus throttle control.
Other throttle options include Digital Rotary Throttle, Two-State Throttle (Idle/Run) or Three-State Throttle
(Idle/Intermediate/Run). The Digital Rotary can be installed with the Throttle Ramp Throttle or Three-State
Throttle to adjust the Idle, Intermediate and Run speeds.
Service Timers
The CP600 display provides sixteen (16) service timers to alert the operator of needed maintenance. The
time interval for each timer can be adjusted in 10 hour increments. A popup message is displayed after the
display self test if a timer has expired alerting the user that service is required. The message is displayed on
each power up until the elapsed timer is disabled or reset.
LOFA CANplus Messenger Telemetry Option
The optional LOFA CANplus Messenger system provides a variety of features to protect and support the
equipment investment. Remote monitoring can alert maintenance requirements, operational problems,
improper operation and location with geo-fence alert. The Web-browser interface allows monitoring an
entire fleet of equipment in a central location. Contact Yanmar for more information.
When replacement parts are required, Yanmar recommends using replacement parts
supplied by Yanmar or parts with equivalent specifications.
Failure to heed this warning could lead to premature failure,
product damage, personal injury or death.
