600 Control Panel Operation and Troubleshooting
28 463-3000-09 Initial - 16-May-2008
Control System Troubleshooting
Control system does not perform self test
Possible Cause Possible Remedy
Tripped overcurrent protection Correct fault, replace or reset overcurrent protection
Faulty connection to battery Correct battery connections (see Battery Circuit Requirements)
Faulty control system Repair or replace control system
Control system performs normal self test, engine cranks, runs and shuts down
Possible Cause Possible Remedy
Engine Stop LED illuminated Correct ECU stop condition, use ECU diagnostics
Display does not display data
Possible Cause Possible Remedy
Display lost power Turn on key, verify display plugged into harness
Engine Source address
incorrect
Change Engine Address in Configuration
Display Address incorrect Change Display Address to 40 (default)
Display configuration problem Reset display using Restore Defaults
CANbus failure Check CANbus (see Testing CANbus)
ECU not sending data Repair or replace ECU
