EF494T OM
25
Clutch pedal
(A) Clutch pedal
To disengage the clutch function, quickly depress the
pedal. To engage, slowly release the pedal. Do not keep
your foot on the clutch pedal unless necessary.
Otherwise, the lifetime of the clutch may be reduced.
Differential lock pedal
WARNING
Never fail to turn off the differential lock to make a turn.
Otherwise, you cannot make an intended turn and an
accident may result.
(A) Differential lock pedal
(B) Release lock
(C) Press to activate differential lock
This pedal makes both side wheels to turn as a
consolidated form if one of rear wheels idles. This
arrangement is useful to avoid slippage in muddy
conditions.
Depressing the pedal automatically causes a differential
lock condition. Releasing the pedal unlocks the
differential system.
2WD/4WD lever
(A) Front wheel drive lever
(B) ON: Four-wheel drive
(C) OFF: Two-wheel drive
This lever is used to switch between two and four-wheel
drive.
