Yanmar EF494T - Adjusting Clutch; Adjusting Steering Wheel

EF494T OM
68
14. Adjusting clutch
Standard version
Depress the clutch pedal to see it there is a specified
play of 15-25 mm. It not, adjust the turnbuckle for a play
of 15-25 mm. Securely lock the nut after adjustment.
(A) Play 15-25 mm
(B) Turn buckle
15. Adjusting steering wheel
WARNING
Check a play for the steering wheel. It should be within a
tolerable range. Otherwise, an accident may occur.
Turn the steering wheel slightly left and right to see if
there is a play of 20-50 mm. Improper play will fail to
provide the smoothness and linearity of steering
function. If a play is not adequate, contact your service
representative.
(A) Play
