8. Replacing radiator screen and air
cleaner elements
The air cleaner serves to keep the engine in favorable
conditions by removing dust in air and preventing the
cylinder liner and piston ring from wearing.
For operation in a dusty environment, clean the air
cleaner element every 50 hours and replace it every 300
hours.
For operation in a normal condition, clean it every 100
hours and replace it every 1000 hours. Even before the
said intervals, replace it every year.
Cleaning air cleaner element
(1) Open the bonnet.
(2) Remove the sub tank.
(3) Open the lid and take out the element.
(A) Air cleaner (Outer)
(B) Air cleaner (Inner)
(4) Blow air from inside of the element or lightly pat it
to take off dust. Be careful not to damage the fins.
IMPORTANT
When the inner element (B) is dirty, replace it. It cannot
be cleaned.
Cleaning radiator screen
Pull the radiator screen upward and remove straws and
dust from it.
(A) Radiator screen
