Lx410/450/490 Operator's Manual
PICTOGRAPHS
To help assist the operator in operating the tractor, various easy to understand pictographs have been created
and are used throughout the Operator's Manual. The pictographs are listed below together with the
corresponding meanings.
Safety alert symbol
<Instrument panel>
Fuel level
Glow
Engine oil pressure
Alternator/Battery charging condition
Engine speed
Hour meter
Engine coolant temperature
Revolutions Per Minute (rpm)
Power Take Off (PTO)
Parking brake
<Lights>
Turn signal
Headlight high
Headlight low
Hazard warning lights
<Starter key switch>
Engine start
Engine run
Engine shut-off
<Levers and knobs>
Power Take Off (PTO) OFF position
Power Take Off (PTO) ON position
Differential lock
Implement control lock/unlock
4-wheel drive on
2-wheel drive on
Slow
Fast
Position control raised position
Position control lowered position
Hydraulic flow control/stop
Tilt pedal lock/unlock
Parking brake lock/unlock
