A: From inside the assembly attach Roof to Beam Brackets to Beam Assemblies with two #12 x 1-1/2” Pan
Screw per bracket. (g. 22.1 and 22.2)
Hardware
28 x #12 x 1-1/2” Pan Screw
x 3
Step 22: Secure Roof to Beam Brackets
Inside View
Beam Assembly
Fig. 22.1
Fig. 22.2
Roof to
Beam
Bracket
#12 x 1-1/2”
Pan Screw
Beam
Assembly
