YARDMAX YS2565 - Machine Assembly Procedures; Beam Pivot Bracket Assembly Steps

18 X 135 X 1
1
Bridge Pin X 1
M10 X 35 X 6
2
YS2565
YS2865
YS3065
M10 X 35 X 4
2
YS3567
M10 X 20 X 2
M12 X 80 X 2
3
M22 X 1
4
4 X 50 X 1
X 1
M12 X 30 X 4
5
M22 X 1
6
4 X 50 X 1
X 1
M10 X 25 X 2
7
X 1
8
X 1
6 X 40 X 2
M8 X 20 X 8
9
M8 X 20 X 2
10
M12 X 35 X 8
11
M10 X 25 X 4
12
OPTIONAL
This log splitter was partially assembled at the factory. To assemble your machine follow the below instructions.
ASSEMBLY
BEAM PIVOT BRACKET
2. Follow the same procedure to disassemble the triangle bracket
from the right beam mount of unit.
3. Slowly pull the beam in a straight line until the pivot casing
in the tank pivot mount is locked by the U-shaped bracket in
the beam. Then make sure the hole in the beam pivot bracket
aligns with the pivot hole in the tank pivot mount. (See Figure
2b.)
1. Disassemble the triangle bracket from the left beam mount of
unit. (Remove the bolts and nuts, See Figure 2a.)
4. Insert the pivot bolt and secure with the bridge pin.
If beam is pulled left or to the right, this could cause
instability of the product and could result in injury.
5. Wheels
6. Manual Tube
7. Tow Bar
8. Log Stripper
9. Log Cradle (Left)
10. Log Cradle (Right)
11. Beam Lock Bracket
12. Mufer (YS2565 and YS2865 only)
13. Operator’s Manual and Engine Manual
14. Tools for Spark Plug Assembly (YS2565 and YS2865 only)
15. Log Table (Optional)
16. Hardware Kit, Including:
16 mm
13 mm
18 mm
19 mm
X 2
YS2565PM01 - 1609
11
|
Contents Supplied & Assembly
Figure 2a
