YARDMAX YS2565 - Parts List for YS2565;YS2865 Models

YS2565/YS2865 PARTS LIST
No. Description Qty
37 Key 3x25 1
38 Gear Pump Connector Left 1
39 Elastic Spider Block 1
40 Gear Pump Connector Right 1
41 Key 3/16x30 1
42 Screw M4x10 4
43 Spring Washer 4 4
44 Nut M12 4
45 Screw M6x10 4
46 Pump Bracket 1
47 Engine 1
48 135° 1/2" Fitting 1
49 Gear Pump 1
50 Washer 8 24
51 Spring Washer 8 20
52 Bolt M8x20 14
53 Lock Latch 1
54 Bolt M8x10 4
55 Pressure Spring 2
56 Washer 14 2
57 Cover of Pump Bracket 1
58 Pin 6x40 3
59 Beam Lock Bracket 1
60 Bolt M10x25 2
61 Washer 30 1
62 Pin 18x135 1
63 Safety Pin
12x125 1
64 Nut M8 4
65 Hose Clamp 1
66 Bolt 6x20 1
67 Lock Nut M6 1
68 Locating Plunger of Log Spinner 1
69 Manual Tube 1
70 Log Craddle-Right 1
71 Bolt 5/16 4
72 Fender-Right 1
No. Description Qty
73 Tire 2
74 Washer 22 2
75 Nut M22 2
76 Dust Cap 2
77 Cotter Pin 4x50 2
78 Bolt M12x30 5
79 Bolt M6x16 6
80 Washer 6 7
81 Flange of lter 1
82 Filter HU-63x80 1
83 O-Ring D81x3.1 1
84 Tank Weldment 1
85 Wheel Axle 1
86 Bolt M8x45 4
87 Washer 20 1
88 Oil Plug 1
89 Support Leg 1
90 Fender-Left 1
91 U-shaped Lock Pin 1
92 Clamp 32 2
93 Suction Hose 1
94 Tow bar 1
95 Bolt M10x85 1
96 2" Ball Coupler Hitch 1
97 Bolt M12x80 4
98 Safety Chain 2
99 Spring Washer 12 4
100 Flat Washer 4 4
101 Spring Washer 6 6
102 Big Washer 18 1
103 Shock Pad 4
104 Big Washer 8 8
105 Big Bridge Pin 1
106 Protective Strip 1
107 Anti-Dust Washer 2
108 Bridge Pin 1
No. Description Qty
1 Welded Hose 1
2 U hoop 1
3 High Pressure Supply Hose 1
4 135° Fitting 1 1
5 Control Valve 1
6 135° Fitting 2 1
7 Log Stripper Weldment 1
8 Quick Link 2
9 4-Way Wedge 1
10
Hexagon Recessed Head Screw M12x55 6
11 Log Craddle-Left 1
12 Washer 12 32
13 Bolt M12x35 8
14 Lock Nut M12 12
15 Circlip 29 1
16 Beam Weldment 1
17 Log Spinner 1
18 Lock Nut M14 1
19 Washer 14 2
20 Flange Nut M12 6
21 Wedge 1
22 Bolt 14x90 1
23 Guide Slide 2
24 Retainer Slide 2
25 Flat Washer 10 24
26 Spring Washer 10 8
27 Bolt M10x35 6
28 Dipstick 1
29 Trunnion Mount 1
30 Low Pressure Return Hose 1
31 Valve Straight Fitting 1/2" 1
32 Hydraulic Cylinder Handlebar 1
33 Right-Angle Fitting 1/2" 2
34 Cylinder 1
35 Nut M10 2
36 Handlebar Grip 2
YS2565PM01 - 1609
29
|
Parts List
