YASKAWA A1000 User Manual

9 UL Standards
YASKAWA ELECTRIC TOEP C710616 27D YASKAWA AC Drive - A1000 Quick Start Guide 41
Model
CIMR-A
Terminal
For Europe and
China <1>
For U.S.A <2> For Asia <3>
Screw
Size
Tightening
Torque
N"m (lb.in.)
Recommen
ded Gauge
mm
2
Applicable
Gauge
mm
2
Recommen
ded Gauge
AWG, kcmil
Applicable
Gauge
AWG, kcmil
Recommen
ded Gauge
mm
2
Applicable
Gauge
mm
2
4A0002
4A0004
R/L1, S/L2, T/L3 2.5 2.5 to 6 14 14 to 10 2 2 to 5.5
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/
T3
2.5 2.5 to 6 14 14 to 10 2 2 to 5.5
–, +1, +2 – 2.5 to 6 – 14 to 10 2 2 to 5.5
B1, B2 – 2.5 to 6 – 14 to 10 2 2 to 5.5
2.5 2.5 to 4 12 14 to 12 2 2 to 5.5
4A0005
4A0007
4A0009
R/L1, S/L2, T/L3 2.5 2.5 to 6 14 14 to 10 2 2 to 5.5
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/
T3
2.5 2.5 to 6 14 14 to 10 2 2 to 5.5
–, +1, +2 – 2.5 to 6 – 14 to 10 2 2 to 5.5
B1, B2 – 2.5 to 6 – 14 to 10 2 2 to 5.5
2.5 2.5 to 6 10 14 to 10 3.5 2 to 5.5
4A0011
R/L1, S/L2, T/L3 2.5 2.5 to 6 12 14 to 10 2 2 to 5.5
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/
T3
2.5 2.5 to 6 14 14 to 10 2 2 to 5.5
–, +1, +2 – 2.5 to 6 – 14 to 10 2 2 to 5.5
B1, B2 – 2.5 to 6 – 14 to 10 2 2 to 5.5
2.5 2.5 to 6 10 14 to 10 3.5 2 to 5.5
4A0018
R/L1, S/L2, T/L3 2.5 2.5 to 16 10 12 to 6 3.5 2 to 14
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/
T3
2.5 2.5 to 16 10 12 to 6 3.5 2 to 14
–, +1, +2 – 4 to 16 – 12 to 6 3.5 2 to 14
B1, B2 – 4 to 6 – 12 to 10 2 2 to 5.5
2.5 2.5 to 6 10 14 to 10 3.5 2 to 5.5 M5
2 to 2.5
(17.7 to 22.1)
4A0023
R/L1, S/L2, T/L3 4 2.5 to 16 10 10 to 6 5.5 3.5 to 14
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/
T3
4 2.5 to 16 10 10 to 6 5.5 3.5 to 14
–, +1, +2 – 4 to 16 – 12 to 6 5.5 3.5 to 14
B1, B2 – 4 to 6 – 12 to 10 2 2 to 5.5
4 4 to 6 10 12 to 10 3.5 3.5 to 5.5 M5
2 to 2.5
(17.7 to 22.1)
4A0031
R/L1, S/L2, T/L3 6 6 to 16 8 8 to 6 14 5.5 to 14
M5
2 to 2.5
(17.7 to 22.1)
U/T1, V/T2, W/
T3
6 6 to 16 8 10 to 6 8 5.5 to 8
–, +1, +2 – 6 to 16 – 10 to 6 14 5.5 to 14
B1, B2 – 6 to 10 – 10 to 8 3.5 2 to 8 M5
2 to 2.5
(17.7 to 22.1)
6 6 to 10 8 10 to 8 5.5 5.5 to 8 M6
4 to 6
(35.4 to 53.1)
4A0038
R/L1, S/L2, T/L3 10 10 to 16 6 8 to 6 14 14
M5
2 to 2.5
(17.7 to 22.1)
U/T1, V/T2, W/
T3
6 6 to 16 8 8 to 6 14 8 to 14
–, +1, +2 – 6 to 16 – 6 14 14
B1, B2 – 6 to 10 – 10 to 8 5.5 3.5 to 8 M5
2 to 2.5
(17.7 to 22.1)
10 6 to 16 6 10 to 6 8 5.5 to 14 M6
4 to 6
(35.4 to 53.1)

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
