Note: 1. Model CIMR-A4A1200 is UL compliant when the air entering the drive-installed panel or cabinet is 45°C or less. For more
information, contact your nearest Yaskawa representative or our sales office.
2. Use crimp insulated terminals or insulated tubing for wiring these connections. Wires should have a continuous maximum allowable
temperature of 75°C 600 V UL approved vinyl sheathed insulation. Ambient temperature should not exceed 40°C.
4A1200
<4>
R/L1, S/L2, T/L3,
R1/L11, S1/L21,
T1/L31
(95 × 4P) × 2 95 to 150 (300 × 4P) × 2 4/0 to 300 (125 × 4P) × 2 100 to 150
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/
T3
(95 × 4P) × 2 95 to 150 (300 × 4P) × 2 4/0 to 300 (125 × 4P) × 2 100 to 150
–, +1 – 120 to 150 – 250 to 300 (150 × 4P) × 2 125 to 150
+3 – 95 to 150 – 4/0 to 300 (100 × 4P) × 2 100 to 150
95 × 4P 95 to 120 4/0 4/0 to 250 125 100 to 125
<1> Gauges listed here are for use in Europe and China.
<2> Gauges listed here are for use in the United States.
<3> Gauges listed here are for use in Asia except for China.
<4> Drive models CIMR-A4A0058 to 4A1200 require the use of closed-loop crimp terminals for UL/cUL compliance. Use only the tools
recommended by the terminal manufacturer for crimping.
