9 UL Standards
YASKAWA ELECTRIC TOEP C710616 27D YASKAWA AC Drive - A1000 Quick Start Guide 45
Closed-Loop Crimp Terminal Recommendations
Yaskawa recommends using closed-loop crimp terminals on all drive models. UL approval requires the use of crimp
terminals when wiring the drive main circuit terminals on models CIMR-A2A0110 to 2A0415 and 4A0058 to 4A1200.
Use only crimping tools as specified by the crimp terminal manufacturer. Yaskawa recommends crimp terminals made by
JST and Tokyo DIP (or equivalent) for the insulation cap.
The table below matches the wire gauges and terminal screw sizes with Yaskawa - recommended crimp terminals,
tools, and insulation caps. Refer to the appropriate Wire Gauge and Torque Specifications table for the wire gauge and
screw size for your drive model. Place orders with a Yaskawa representatives the Yaskawa sales department.
Wire Gauge
Terminal
Screws
Crimp Terminal
Model Number
Tool
Insulation Cap
Model No.
Code <1>
Machine No. Die Jaw
2 mm
2
14 AWG
<1> Codes refer to a set of three crimp terminals and three insulation caps. Prepare input and output wiring using two sets for each connection.
Example 1: Models with 300 kcmil for both input and output require one set for input terminals and one set for output terminals, so the user
should order two sets of [100-051-272].
Example 2: Models with 4/0 AWG × 2P for both input and output require two sets for input terminals and two sets for output terminals, so the
user should order four sets of [100-051-560].
M4 R2-4 YA-4 AD-900 TP-003 100-054-028
3.5 / 5.5 mm
2
12 / 10 AWG
M4 R5.5-4 YA-4 AD-900 TP-005 100-054-029
M5 R5.5-5 YA-4 AD-900 TP-005 100-054-030
8 mm
2
8 AWG
M4 8-4 YA-4 AD-901 TP-008 100-054-031
M5 R8-5 YA-4 AD-901 TP-008 100-054-032
14 mm
2
6 AWG
M4 14-NK4 YA-4 AD-902 TP-014 100-054-033
M5 R14-5 YA-4 AD-902 TP-014 100-054-034
M6 R14-6 YA-5 AD-952 TP-014 100-051-261
M8 R14-8 YA-5 AD-952 TP-014 100-054-035
22 mm
2
4 AWG
M6 R22-6 YA-5 AD-953 TP-022 100-051-262
M8 R22-8 YA-5 AD-953 TP-022 100-051-263
30 / 38 mm
2
3 / 2 AWG
M8 R38-8 YA-5 AD-954 TP-038 100-051-264
50 / 60 mm
2
1 AWG
1/0 AWG
1/0 AWG × 2P
M8 R60-8 YA-5 AD-955 TP-060 100-051-265
M10 R60-10 YF-1, YET-300-1 TD-321, TD-311 TP-060 100-051-266
1 AWG × 2P
2 AWG × 2P
M10 38-L10 YF-1, YET-150-1 TD-224, TD-212 TP-038 100-051-556
80 mm
2
2/0 / 3/0 AWG
2/0 AWG × 2P
M10 80-10 YF-1, YET-300-1 TD-323, TD-312 TP-080 100-051-267
3/0 AWG × 2P
3/0 AWG × 4P
M10 80-L10 YF-1, YET-150-1 TD-227, TD-214 TP-080 100-051-557
M12 80-L12 YF-1, YET-300-1 TD-323, TD-312 TP-080 100-051-558
100 mm
2
4/0 AWG
M10 R100-10
YF-1, YET-300-1
YF-1, YET-150-1
TD-324, TD-312
TD-228, TD-214
TP-100 100-051-269
4/0 AWG × 2P
4/0 AWG × 4P
M10 100-L10 YF-1, YET-150-1 TD-228, TD-214 TP-100 100-051-559
M12 100-L12 YF-1, YET-300-1 TD-324, TD-312 TP-100 100-051-560
150 mm
2
250 / 300 kcmil
M10 R150-10 YF-1. YET-150-1 TD-229, TD-215 TP-150 100-051-272
M12 R150-12 YF-1, YET-300-1 TD-325, TD-313 TP-150 100-051-273
250 kcmil × 2P
250 kcmil × 4P
300 kcmil × 2P
300 kcmil × 4P
M10 150-L10 YF-1, YET-150-1 TD-229, TD-215 TP-150 100-051-561
M12 150-L12 YF-1, YET-300-1 TD-325, TD-313 TP-150 100-051-562
200 mm
2
350 kcmil
400 kcmil
M10 200-10 YF-1, YET-300-1 TD-327, TD-314 TP-200 100-051-563
M12 R200-12 YF-1, YET-300-1 TD-327, TD-314 TP-200 100-051-275
350 kcmil × 2P
400 kcmil × 2P
M12 200-L12 YF-1, YET-300-1 TD-327, TD-314 TP-200 100-051-564
325 mm
2
500 kcmil
600 / 650 kcmil
500 kcmil × 2P
600 kcmil × 2P
M10 325-10 YF-1, YET-300-1 TD-328, TD-315 TP-325 100-051-565
M12 325-12 YF-1, YET-300-1 TD-328, TD-315 TP-325 100-051-277
