Programming 70
The Drive has 6 multi-function contact digital inputs. By programming parameters H1-01 through H1-06, the user can assign specific
functions to each input. Below is a table with a complete list of all of the digital input functions according to control method (A1-02).
Not all functions are available for all control methods. Following the table is a more detailed description of each of the functions.
Table 13 Multi-Function Input Selection
Parameter
Setting
Function
Control Method (A1-02)
V/f
V/f with
PG
Open
Loop
Vector
Flux
Vector
03-Wire Control OOOO
1Local/Remote Selection OOOO
2Option/Inverter Selection OOOO
3 Multi-Step Frequency Reference 1 (factory default, H1-03) OOOO
4 Multi-Step Frequency Reference 2 (factory default, H1-04) OOOO
5Multi-Step Frequency Reference 3 OOOO
6 Jog Frequency Reference (factory default, H1-05) OOOO
7Accel/Decel Time Selection 1 OOOO
8 External Baseblock N.O. (factory default, H1-06) OOOO
9External Baseblock N.C. OOOO
AAccel/Decel Ramp Hold OOOO
BExternal Overheat Alarm (OH2) OOOO
CTerminal A2 Enable OOOO
DV/f Control with PG Disabled XOXX
EASR Integral Reset XOXO
FTerminal Not Used OOOO
10MOP Increase OOOO
11MOP Decrease OOOO
12Forward Jog OOOO
13Reverse Jog OOOO
14 Fault Reset (factory default, H1-02) OOOO
15Fast-Stop N.O. OOOO
16Motor 2 Selection OOOO
17Fast-Stop N.C. OOOO
18Timer Function OOOO
19PID Disable OOOO
1AAccel/Decel Time Selection 2 OOOO
1B Program Lockout OOOO
1CTrim Control Increase OOOO
1DTrim Control Decrease OOOO
1EReference Sample Hold OOOO
20External Fault, Normally Open, Always Detected, Ramp To Stop OOOO
21External Fault, Normally Closed, Always Detected, Ramp To StopOOOO
22External Fault, Normally Open, During Run, Ramp To Stop OOOO
23External Fault, Normally Closed, During Run, Ramp To Stop OOOO
24
External Fault, Normally Open, Always Detected, Coast to Stop
(factory default, H1-01)
OOOO
25External Fault, Normally Closed, Always Detected, Coast To StopOOOO
26External Fault, Normally Open, During Run, Coast To Stop OOOO
27External Fault, Normally Closed, During Run, Coast To Stop OOOO
28External Fault, Normally Open, Always Detected, Fast-Stop OOOO
29External Fault, Normally Closed, Always Detected, Fast-Stop OOOO
2AExternal Fault, Normally Open, During Run, Fast-Stop OOOO
2BExternal Fault, Normally Closed, During Run, Fast-Stop OOOO
2CExternal Fault, Normally Open, Always Detected, Alarm Only OOOO
2DExternal Fault, Normally Closed, Always Detected, Alarm Only OOOO
2EExternal Fault, Normally Open, During Run, Alarm Only OOOO
2FExternal Fault, Normally Closed, During Run, Alarm Only OOOO
30PID Integral Reset OOOO
31PID Integral Hold OOOO
32Multi-Step Reference 4 OOOO
34PID Soft Starter Cancel OOOO
