Table C.1 Factory Recommended Drive Branch Circuit Protection
Drive Model
Fuse Type
Manufacturer: Bussmann
Model Fuse Ampere Rating (A)
Single-Phase 200 V Class
BA0001 FWH-25A14F 25
BA0002 FWH-25A14F 25
BA0003 FWH-60B 60
BA0006 FWH-80B 80
BA0010 FWH-100B 100
Three-Phase 200 V Class
2A0001 FWH-25A14F 25
2A0002 FWH-25A14F 25
2A0004 FWH-25A14F 25
2A0006 FWH-25A14F 25
2A0008 FWH-70B 70
2A0010 FWH-70B 70
2A0012 FWH-70B 70
2A0018 FWH-90B 90
2A0020 FWH-90B 90
Three-Phase 400 V Class
4A0001 FWH-40B 40
4A0002 FWH-40B 40
4A0004 FWH-50B 50
4A0005 FWH-70B 70
4A0007 FWH-70B 70
4A0009 FWH-90B 90
4A0011 FWH-90B 90
n
Grounding
The drive is designed to be used in T-N (grounded neutral point) networks. If installing the
drive in other types of grounded systems, contact your dealer or Yaskawa for instructions.
n
CE Standards Compliance for DC Power Supply Input
Install the fuses in the following tables to meet CE standards.
C.2 European Standards
256
YASKAWA ELECTRIC TOEP C710606 25D YASKAWA AC Drive J1000 Installation & Start-Up Manual
