5 Conditions
14 YASKAWA TOEP C710617 0SB YASKAWA AC Drive GA500 Installation Manual
Table 5.6 Three-Phase 200 V Class (Finless-Type Drive)
Drive Model
Rated Output
Current
(A)
Carrier
Frequency
(kHz)
Drive Watt Loss (W)
Interior Unit
Loss
Heatsink Plate Loss
(P
Loss
)
Total
Loss
2001 0.8 2 6 4 10
2002 1.6 2 7 7 14
2004 3.0 2 9 13 22
2006 5.0 2 13 22 35
2008 6.9 2 14 30 44
2010 8.0 2 17 37 54
2012 11.0 2 23 49 72
2018 14.0 2 26 61 87
2021 17.6 2 36 83 119
2030 25.0 2
46 139 185
2042 33.0 2
67 175 242
2056 47.0 2
95 284 379
2070 60.0 2
157 377 534
Table 5.7 Three-Phase 400 V Class (Finless-Type Drive)
Drive Model
Rated Output
Current
(A)
Carrier
Frequency
(kHz)
Drive Watt Loss (W)
Interior Unit
Loss
Heatsink Plate Loss
(P
Loss
)
Total
Loss
4001 1.2 2 8 7 15
4002 1.8 2 10 10 20
4004 3.4 2 13 21 34
4005 4.8 2 15 29 44
4007 5.6 2 16 33 49
4009 7.3 2 21 45 66
4012 9.2 2 27 60 87
4018 14.8 2
44 105 149
