YASKAWA GA500 series - Heavy Duty Rating (HD): Carrier Frequency = Default Setting

5 Conditions
YASKAWA TOEP C710617 0SB YASKAWA AC Drive GA500 Installation Manual 15
Drive Model
Rated Output
Current
(A)
Carrier
Frequency
(kHz)
Drive Watt Loss (W)
Interior Unit
Loss
Heatsink Plate Loss
(P
Loss
)
Total
Loss
4023 18 2
76 146 220
4031 24 2
62 167 229
4038 31 2
89 222 311
■ Heavy Duty Rating (HD): Carrier Frequency = Default Setting
Table 5.8 Single-Phase 200 V Class (Finless-Type Drive)
Drive Model
Rated Output
Current
(A)
Carrier
Frequency
(kHz)
Drive Watt Loss (W)
Interior Unit
Loss
Heatsink Plate Loss
(P
Loss
)
Total
Loss
B001 0.8 10 8 5 13
B002 1.6 10 10 9 19
B004 3 10 14 16 30
B006 5 10 18 28 46
B010 8 8 31 42 73
B012 11 8 41 55 96
Table 5.9 Three-Phase 200 V Class (Finless-Type Drive)
Drive Model
Rated Output
Current
(A)
Carrier
Frequency
(kHz)
Drive Watt Loss (W)
Interior Unit
Loss
Heatsink Plate Loss
(P
Loss
)
Total
Loss
2001 0.8 10 6 5 11
2002 1.6 10 7 8 15
2004 3.0 10 10 16 26
2006 5.0 10 14 27 41
2008 6.9 8 15 35 50
2010 8.0 8 18 43 61
2012 11.0 8 24 56 80
