YASKAWA GA500 series - Page 25

7 Drive Exterior and Mounting Dimensions
YASKAWA TOEP C710617 0SB YASKAWA AC Drive GA500 Installation Manual 25
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 H1 t1 d
4007
108
(4.25)
128
(5.04)
100
(3.94)
96
(3.78)
118
(4.65)
4
(0.16)
M5
1.0
(2.20)
4009
108
(4.25)
128
(5.04)
100
(3.94)
96
(3.78)
118
(4.65)
4
(0.16)
M5
1.0
(2.20)
4012
140
(5.51)
128
(5.04)
78
(3.07)
128
(5.04)
118
(4.65)
4
(0.16)
M5
1.2
(2.65)
◆ 2030 - 2070, 4018 - 4038
Figure 7.3 Exterior and Mounting Dimensions
