YASKAWA America, Inc. PL.GA500.01 YASKAWA AC Drive - V1000 to GA500 Transition Guide 3
AC Drive Transition Guide
V1000 to GA500
This document is intended to help OEM's, Integrators, and End Users select and replace Yaskawa
V1000 series AC drives with Yaskawa GA500 AC drives. Replacement should be conducted by
qualified personnel familiar with AC drive installation. Follow local electrical codes during
replacement and installation.
1 MODEL IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 REPLACEMENT GA500 DRIVE SELECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 DIMENSIONS AND ADAPTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4 BRANCH CIRCUIT PROTECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 MAIN CIRCUIT AND MOTOR WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6 CONTROL CIRCUIT WIRING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7 TRANSFER OF PARAMETER SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8 CARRIER FREQUENCY - C6-02 [CARRIER FREQUENCY SELECTION]. . . . 40
9 WATT LOSS COMPARISON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10 NETWORK COMMUNICATION AND CONTROL I/O OPTIONS . . . . . . . . . . . . 44
11 OTHER OPTION COMPATIBILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
