9 Watt Loss Comparison
42 YASKAWA America, Inc. PL.GA500.01 YASKAWA AC Drive - V1000 to GA500 Transition Guide
 Heavy Duty (Parameter C6-01=0)
Table 19 Single-Phase 240 V Models, Watt Loss Comparison
Table 20 Three-Phase 240 V Models, Watt Loss Comparison
4A0005 Swing 2 kHz 44.5 21.8 66.3 4005 2.0 16.0 32.0 48.0 -28.5 10.2 -18.3
4A0007 Swing 2 kHz 58.5 28.4 86.9 4007 2.0 20.0 44.0 64.0 -38.5 15.6 -22.9
4A0009 Swing 2 kHz 63.7 31.4 95.1 4009 2.0 28.0 58.0 86.0 -35.7 26.6 -9.1
4A0011 Swing 2 kHz 81.7 46.0 127.7 4012 2.0 39.0 83.0 122.0 -42.7 37.0 -5.7
4A0018 Swing 2 kHz 181.2 80.1 261.3 4018 2.0 52.0 155.0 207.0 -129.2 74.9 -54.3
4A0023 Swing 2 kHz 213.4 107.7 321.1 4023 2.0 86.0 236.0 322.0 -127.4 128.3 0.9
4A0031 Swing 2 kHz 287.5 146.1 433.6 4031 2.0 101.0 284.0 385.0 -186.5 137.9 -48.6
4A0038 Swing 2 kHz 319.2 155.8 475.0 4038 2.0 108.0 341.0 449.0 -211.2 185.2 -26.0
- - - - - 4044 2.0 137.0 417.0 554.0 N/A N/A N/A
- - - - - 4060 2.0 176.0 490.0 666.0 N/A N/A N/A
V1000 GA500 Difference
Model
Carrier
kHz
Watt Loss
Catalog
Code
Watt Loss Watt Loss
CIMR-VU Interior External Total GA50U
Carrier
kHz
Interior External Total Interior External Total
BA0001 8.0 4.3 7.4 11.7 B001 10.0 8.0 5.0 13.0 3.7 -2.4 1.3
BA0002 8.0 7.9 8.9 16.7 B002 10.0 10.0 9.0 19.0 2.1 0.1 2.3
BA0004 8.0 16.1 11.5 27.7 B004 10.0 14.0 16.0 30.0 -2.1 4.5 2.3
BA0006 8.0 33.7 16.8 50.5 B006 10.0 18.0 28.0 46.0 -15.7 11.2 -4.5
BA0010 8.0 54.8 25.9 80.7 B010 8.0 31.0 42.0 73.0 -23.8 16.1 -7.7
BA0012 8.0 70.7 34.1 104.8 B012 8.0 41.0 55.0 96.0 -29.7 20.9 -8.8
BA0018 8.0 110.5 51.4 161.9 B018 8.0 53.0 98.0 151.0 -57.5 46.6 -10.9
V1000 GA500 Difference
Model
Carrier
kHz
Watt Loss
Catalog
Code
Watt Loss Watt Loss
CIMR-VU Interior External Total GA50U
Carrier
kHz
Interior External Total Interior External Total
2A0001 8.0 4.3 7.3 11.6 2001 10.0 6.0 5.0 11.0 1.7 -2.3 -0.6
2A0002 8.0 7.9 8.8 16.7 2002 10.0 7.0 8.0 15.0 -0.9 -0.8 -1.7
2A0004 8.0 16.2 11.5 27.7 2004 10.0 10.0 16.0 26.0 -6.2 4.5 -1.7
2A0006 8.0 27.4 15.9 43.3 2006 10.0 14.0 27.0 41.0 -13.4 11.1 -2.3
2A0010 8.0 54.8 23.8 78.6 2010 8.0 18.0 43.0 61.0 -36.8 19.2 -17.6
2A0012 8.0 70.7 29.9 100.6 2012 8.0 24.0 56.0 80.0 -46.7 26.1 -20.6
2A0020 8.0 110.5 43.3 153.8 2021 8.0 40.0 108.0 148.0 -70.5 64.7 -5.8
2A0030 8.0 231.5 72.2 303.7 2030 8.0 49.0 187.0 236.0 -182.5 114.8 -67.7
2A0040 8.0 339.5 82.8 321.3 2042 8.0 60.0 232.0 292.0 -279.5 149.2 -29.3
2A0056 8.0 347.6 117.6 465.2 2056 8.0 85.0 318.0 403.0 -262.6 200.4 -62.2
2A0069 8.0 437.7 151.4 589.1 2070 8.0 119.0 473.0 592.0 -318.7 321.6 2.9
- - - - - 2082 8.0 148.0 525.0 673.0 N/A N/A N/A
V1000 GA500 Difference
Model
Carrier
kHz
Watt Loss
Catalog
Code
Watt Loss Watt Loss
CIMR-VU Interior External Total GA50U
Carrier
kHz
Interior External Total Interior External Total
