YASKAWA P1000 Safety Precautions

Drive Model Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
N·m (lb.in.)
5A0062
R/L1, S/L2, T/L3 4 10 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 4 10 to 4/0
⊖, ⊕1
– 4 to 4/0
⊕3
– 6 to 4/0
4 4
5A0077
R/L1, S/L2, T/L3 3 10 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 3 10 to 4/0
⊖, ⊕1
– 3 to 4/0
⊕3
– 6 to 4/0
4 4
5A0099
R/L1, S/L2, T/L3 1/0 10 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 1 10 to 4/0
⊖, ⊕1
– 2 to 4/0
⊕3
– 4 to 4/0
4 4
5A0125
R/L1, S/L2, T/L3 2/0 1 to 300
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 2/0 1 to 300
⊖, ⊕1
– 2/0 to 3/0
⊕3
– 1 to 1/0
3 4 to 300
5A0145
R/L1, S/L2, T/L3 3/0 2/0 to 300
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 3/0 2/0 to 300
⊖, ⊕1
– 3/0 to 4/0
⊕3
– 1/0 to 2/0
3 4 to 300
5A0192
R/L1, S/L2, T/L3 300 2/0 to 600
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 250 2/0 to 600
⊖, ⊕1
– 2/0 to 400
⊕3
– 2/0 to 250 M10
18 to 23
(159 to 204)
1 1 to 350 M12
32 to 40
(283 to 354)
5A0242
R/L1, S/L2, T/L3 400 2/0 to 600
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 350 2/0 to 600
⊖, ⊕1
– 2/0 to 500
⊕3
– 250 to 300 M10
18 to 23
(159 to 204)
1 1 to 350 M12
32 to 40
(283 to 354)
Note: When connecting peripheral devices or options to terminals ⊖, ⊕1, ⊕3, B1, and B2 , refer to the instruction manual for each device. For
more information, contact Yaskawa or your nearest sales representative.
i.3 Electrical Installation Safety
30
YASKAWA ELECTRIC TOEP YAIP1U 03B YASKAWA AC Drive – P1000 Safety Precautions

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
