8 YASKAWA ELECTRIC TOBP C730600 75B YASKAWA AC Drive Option PG-B3 Installation Manual
2 Product Overview
2 Product Overview
u About This Product
The PG-B3 Option allows the user to connect an incremental encoder with complementary
output (PG) for motor speed feedback to the drive to increase the control accuracy and
performance in V/f w/PG, CLV, and AOLV control methods.
This PG encoder signal allows the drive to compensate for subtle variations in the load while
providing the drive with the necessary data to control the output frequency and maintain an
accurate constant speed.
The option reads a 50 kHz maximum input frequency from the PG encoder. Select a PG
encoder with 50 kHz maximum output when operating at maximum speed.
u Applicable Models
The option can be used with the drive models in Table 1.
Table 1 Applicable Models
Drive Series Model Number
A1000 All models
L1000A All models
U1000 All models
U1000L All models
GA700 All models
CR700 All models
CH700 All models
TOBP_C730600_75B_1_0_E.book 8 ページ ２０１７年２月１７日 金曜日 午後３時２分
