6 Related Parameters
6 Related Parameters
The parameters in Ta b le 1 0 set the drive for operation with the option. Set parameters as
needed. Refer to the manual packaged with the drive for details on setting parameters.
Table 10 Related Parameters
No.
(Addr. Hex)
Name Description
Control
Method
Values
A1-02
(102)
Control Method
Selection
0: V/f Control
1: Closed Loop V/f Control
2: Open Loop Vector Control
3: Closed Loop Vector Control
4: Advanced Open Loop Vector Control
5: PM Open Loop Vector Control
6: PM Advanced Open Loop Vector
7: PM Closed Loop Vector Control
8 : EZ Open Loop Vector Control
All Modes
Default:
<1>
Range: <1>
F1-01
(380)
<2> <3>
PG 1 Pulses per
Revolution
Sets the number of pulses per motor revolution.
V/f w/ PG
CLV
AOLV
Default:
<1>
Min: <1>
Max: <1>
F1-02
(381)
PG Feedback
Loss Selection
Selects the stopping method after PG disconnect
(PGo).
0: Ramp to stop
1: Coast to stop
2: Fast Stop (Use C1-09)
3: Alarm only
4: No alarm display
NOTICE: Use settings 3 and 4 under special
circumstances only. Failure to comply could damage
the motor and connected machinery.
V/f w/ PG
CLV
AOLV
Default: 1
Range:
<1>
F1-03
(382)
Operation Select
at Overspeed
Selects the stopping method after detecting
overspeed (oS).
0: Ramp to stop
1: Coast to stop
2: Fast Stop (Use C1-09)
3: Alarm only
NOTICE: Use setting 3 under special circumstances
only. Failure to comply could damage the motor and
connected machinery.
V/f w/ PG
CLV
AOLV
Default: 1
Range: 0 to 3
F1-04
(383)
Operation Select
at Overspeed
0: Ramp to stop
1: Coast to stop
2: Fast Stop (Use C1-09)
3: Alarm only
NOTICE: Use setting 3 under special circumstances
only. Failure to comply could damage the motor and
connected machinery.
V/f w/ PG
CLV
AOLV
Default:
<1>
Range: 0 to 3
